INTRODUCTION

Environmental pollution has become such a serious problem, that as ^{Plath et al. (2015}) stated: More and more aquatic habitats are currently becoming extreme to fishes due to novel stressors stemming from human activities. These stressors can potentially impair, in different ways, the sustainability of aquatic ecosystems. Particularly, several xenobiotics present in urban wastewaters dumped into limnetic ecosystems have shown to impair fish reproductive behavior, physiology, and morphology. Fragmentation of urban lagoons can accelerate ecological impairment through the exponential accumulation of pollutants in water and the isolation of fish populations in a limited area. Moreover, highly volatile estrogenic compounds can be transported in the atmosphere from remote sites, without any hydraulic connection among sites (^{Schwaiger et al. 1997}). All of this has caused an increasing interest in evaluating the current health status of urban aquatic ecosystems, aiming to drive restoration and conservation strategies (e.g. ^{Dunalska et al. 2015}). Fish are particularly useful for environmental impact assessment studies because of their over-sensitiveness for incorporating pollutants both directly from water and indirectly through the trophic web (^{Magar and Bias 2013}). Many of these compounds can directly disrupt various physiological processes, even in very low concentrations; meanwhile others indirectly act through changes in physicochemical properties of water (^{Steinhagen et al. 1989}). Previous studies have shown that xenobiotic compounds can inhibit immunological responses in fish at different levels, increasing their vulnerability to infectious diseases (^{Dunier 1996}). On the other hand, some studies have reported an increase of fish’s immune response from polluted ecosystems exposed to heavy metals in water (^{Schwaiger et al. 1997}). Chronic exposure to certain xenobiotics cause reproductive abnormalities in different fish species and this can be evaluated by means of biomarkers of environmental stress. Among these, histopathology of several organs has proven to be a useful tool for xenobiotic identification in marine and freshwater environments (^{Louiz et al. 2009}). Gonadal histopathology is particularly important because it allows identifying alterations in the reproductive fitness of a given species and so determining their risk status in habitat (^{Feist et al. 2015}). On that basis, this research analyzed the histopathology of four fish species inhabiting at the urban lagoon La Pólvora; the cichlids Thorichthys helleri and Thorichthys meeki, the clupeid Dorosoma petenense and the non-native loricariid Pterygoplichthys spp., which may show different sensitivities to aquatic pollution, as it has been documented in several teleost species inhabiting polluted environments (^{Norey et al. 1990}). Given that La Pólvora urban lagoon is a reservoir with high levels of organic pollution (^{Sánchez et al. 2012}), the aim of this study was to determine the presence of histopathological alterations in gonads of these four fish species.

MATERIALS AND METHODS

RESULTS AND DISCUSSION

A total of thirty-one specimens were collected at La Pólvora; Dorosoma petenense (12), Thorichthys meeki (10), Thorichthys helleri (4), and Pterygoplichthys spp. (5). Histopathology has been recognized as a sensitive tool to identify tissue alterations induced by various water pollutants (^{Stentiford et al. 2014}). In this study, the most severe histopathological alteration was observed in the testes of D. petenense, which showed generalized testicular degeneration (Fig. 1) and disintegration of seminiferous lobules, due to fragmentation of basement membrane. In Cichlasoma dimerus this condition was attributed to endosulfan exposure, a common fertilizer used in agriculture (^{Da Cuña et al. 2013}). In gonads of D. petenense and T. meeki just some melanomacrophage centers (MMCs) were observed in the interstitial compartment (images not shown) as groupings of macrophages containing intracellular pigments such as melanin, lipofuscin, and hemosiderin, as it has been reported in other fish species (^{Agius and Roberts 2003}). MMCs have been used as environmental stress biomarkers in several teleost species, given that their presence is considered an immunological response to numerous contaminants and pathogens (^{Blazer 2002}). The low presence of MMCs in D. petenense and T. meeki could be interpreted as absence of environmental stressors. However, in view of the recurrence of other serious histopathological abnormalities in these organisms, it may be toxic compounds at La Pólvora negatively modulating the immune system and increasing the vulnerability of these species to disease (^{Bols et al. 2001}). In fact, an intense and generalized immunological reaction of acidophilic cells was only observed in one specimen of D. petenense (image not shown).

Fig. 1 Testis degeneration in the clupeid Dorosoma petenense. Generalized tissue degeneration (TDG) produced by detachment and fragmentation of basement membrane (arrows, inset) delimiting seminiferous lobules. The scattered nuclei from spermatozoa are showed (arrow), 100X

Particularly, frequent protozoan infections observed in testes of D. petenense and T. meeki (Fig. 2) support the hypothesis of immunological impairment, because parasitic diseases are related to the increase of organic concentrations and temperatures in polluted waters (^{Anderson 1990}), a condition determined in La Pólvora by ^{Sánchez et al. (2012}). Notably, females did not show parasitic infection in ovaries, suggesting that this pathological condition is also influenced by the sex of the host. However, the most common alterations in ovaries of D. petenense were follicular epithelium expansion, fracture of follicular basement membrane (Fig. 3), follicular atresia, and interstitial proteinaceous fluid accumulation (IPF) (Fig. 4). In all species included in this study, follicular atresia consisted of progressive degeneration of the follicular structure. Atretic follicles of D. petenense showed oocyte cytoplasmic vacuolization, fracture of the zona pellucida as well as follicular epithelium hypertrophy. Although atresia is a normal degenerative process influenced by the fertility index of each species (^{Uribe-Aranzábal et al. 2006}), its rate may be influenced by a range of pollutants such as organochlorine pesticides, malathion, petroleum compounds, and aromatic hydrocarbons (^{Mlambo et al. 2009}, ^{Bols et al. 2001}), as well as ecological disturbances that generate stress in female fish (^{Overstreet 1988}). Despite follicular atresia was regularly observed in all of fish considered herein, its recurrence was highest in D. petenense, according with a generalized destruction of ovarian tissues. The IPF presence in the ovarian stroma of D. petenense was also documented in the fathead minnow Pimephales promelas and attributed to estrogenic compounds exposure, which may induce extracellular accumulation of vitellogenins (^{USEPA 2006}). However, in the tilapia Oreochromis mossambicus and zebrafish Danio rerio FPI presence was attributed to vitellogenic oocyte degeneration induced by chemical exposure (^{Mlambo et al. 2009}, ^{van der Ven et al. 2003}). In this study, gonadal histopathological alterations in T. helleri and Pterygoplichthy spp. were absent, but this does not exclude them of disruptions at other biological organization levels. In fact, sensitiveness variations of physiological systems facing environmental stressors should be an essential topic in biomonitoring programs, because xenobiotics harm fish populations first at molecular, biochemical, and cellular levels. Only when physiological mechanisms cannot restore homeostatic balance, pathological effects appear in higher levels of biological complexity as morphology and behavior (^{Rice et al. 1996}). Based on this, possible alterations may occur in most basal levels of biological organization of fish from La Pólvora, but complementary studies will be necessary to test this hypothesis and establish a clear connection between pathological alterations and the presence of specific pollutants in urban waters.

Fig. 2 Testis alterations induced by pathogenic infection in the cichlid Thorichthys meeki. Interstitial (INT) and germinal compartment (GER), the latter saturated with spermatozoa inside seminiferous lobules (blue). Testicular parenchyma presents numerous orifices caused by parasitic infection (arrow), 100X. Infection is also accompanied by vascular hypertrophy of the interstitial compartment (star). The pathogenic agents, protozoa, are clearly observed into a seminiferous lobule (inset), 400X

Fig. 3 Expansion of the follicular epithelium in vitellogenic oocytes of Dorosoma petenense. In some vitellogenic oocytes (VOC) the follicular epithelium is expanded due to accumulation of intracellular fluid (EX), causing rupture of basement membrane (arrow) and structural deterioration of follicles. A previtellogenic oocyte (POC) with follicular epithelium detachment is also observed, 400X

Fig. 4 Ovarian alterations in Dorosoma petenense. Intersticial proteinaceus fluid (FL) surrounding previtellogenic and vitellogenic oocytes with ooplasmic retraction and detachment of follicular epithelium (arrows). Atretic vitellogenic oocytes with cytoplasmic vacuolization, hypertrophied follicular epithelium, and zona pellucida fragmentation,100X
