Introduction

Carbon (C) on the planet (43 515 ± 10 000 Pg) is found mainly in geological reservoirs (identified as carbon, gas and oil [5 000 to 10 000 Pg]), oceans (87 %, with a predominance of C-inorganic), atmosphere (2 %, mainly as carbon dioxide [CO₂]) and land (which includes soil and plant biomass [11 %]). Soil organic carbon (SOC) is estimated to be three times higher (1 500 Pg) than that concentrated in aboveground vegetation (450 Pg) (^{García-Oliva et al., 2006}; ^{Venter et al., 2021}; ^{Zhuo-Dong et al., 2021}).

It has been extensively reported that SOC is determined by the quantity and vertical distribution of vegetation, intrinsic soil properties, and climate. However, the variability of SOC is influenced by anthropogenic interference, commonly carried out by soil manipulation practices (tillage, fertilization), vegetation modification (clearing, thinning, etc.) and livestock pressure, among others (^{Jobbagy & Jackson, 2000}; ^{García-Oliva et al., 2006}; ^{Muñoz et al., 2015}; ^{Batjes, 2016}; ^{Venter et al., 2021}; ^{Zhuo-Dong et al., 2021}).

^{Venter et al. (2021)} mention that since the beginning of livestock and agriculture (12 000 years ago), land use changes and overgrazing have caused a loss of 116 Pg of C from the topsoil up to 2 m depth, where the main ecosystems affected are grasslands, savannas and croplands (22, 22 and 21 Pg, respectively). Even when in some areas there is an increase in SOC by appropriate interventions, such as the incorporation of green manures and restrictions on vegetation removal (^{Parras-Alcántara et al., 2015}; ^{Mahajan et al., 2021}), net balance to date is negative, because overall losses are estimated at an average of 26 % (^{Venter et al., 2021}).

Because of the importance of SOC in soil functions and its interaction with the plant-atmosphere system, it is now considered as a universal indicator of soil safety and health (^{McBratney et al., 2014}; ^{Mattina et al., 2018}; ^{Food and Agriculture Organization of the United Nations [FAO], 2017a}). In contrast, SOC loss is an indicator of soil degradation (^{Loayza et al., 2020}; ^{Mahajan et al., 2021}), which is consistent with the behavior of moisture, and soil and air temperature (^{Gómez-Tagle et al., 2003}; ^{López-Santos et al., 2008}). ^{López-Santos et al. (2008)} found that in soils poor in organic matter (< 3 %) and without vegetation protection, the behavior of energy in the topsoil (8 cm depth) is unpredictable, which is manifested in the increase in sensible heat.

In the Target 15.3 of the Sustainable Development Goals (SDGs) (^{FAO, 2017b}), the SOC is considered as an indicator of biodiversity and resilience to climate change; this under the premise of promoting and achieving Land Degradation Neutrality (LDN), which is one of the three indicators considered as “trends in carbon stocks” (^{Orr et al., 2017}; ^{Laban et al., 2018}). However, as mentioned above, due to multiple biotic and abiotic factors, including soil type, land use, and climatic conditions (^{Galicia et al., 2016}), SOC stocks are not static, because they are subject to constant cycling among various sinks, in soil, vegetation, ocean, and atmosphere.

From the local, to the global scale, it is complicated to quantify SOC stocks. Therefore, ^{FAO (2017c)} compiled statistical methods based on Geographic Information Systems (GIS) to generate spatially distributed digital SOC maps (SOCDM), namely, to assess SOC considering uncertainty. This effort was aimed to support developing countries, such as those located in Latin America, because in several of them a scarcity or, in extreme cases, absence of soil data was detected (^{Guevara et al., 2018}).

^{Guevara et al. (2018)}, as part of integration efforts of the SOC world map (http://54.229.242.119/GSOCmap/), elaborated the SOCDM of Latin America with a spatial resolution of 5 x 5 km. These authors used 11 268 estimates (n) from 19 countries, out of the 46 that integrate the region. The largest contribution of soil data (88.1 %) was from Brazil (5 616 n) and Mexico (4 321 n); other countries such as Argentina (231 n), Colombia (166 n) and Venezuela (1.45 n) had a joint contribution of less than 5 %. For this purpose, they used the SCORPAN model previously described by ^{McBratney et al. (2003)}. ^{Guevara et al. (2018)} mention that from that model they combined quantitative and qualitative empirical descriptions to establish the relationship between soils and spatially distributed predictors: Sc = ꬵ(S,C,O,R,P,A,N) and Sa = f(S,C,O,R,P,A,N); where Sc corresponds to soil classes and Sa can be any soil attribute or attributes (such as SOC), which will depend on the characteristics of soil (S), climate (C), organisms (O), relief (R), parent material (P), time (A) and physical space (N).

However, in the report by ^{Guevara et al. (2018)}, SOC estimates for Latin America and the Caribbean still present uncertainties reflected in standard deviations above the mean values (Brazil = 3.23 ± 9.18 kg de SOC·m^-2). Mexico reports an average SOC storage of 2.56 ± 1.49 kg·m^-2 (in a range from 0 to 35.55 kg·m^-2), which represents a national average of about 7.68 t·ha^-1 of SOC considering a depth of 30 cm. Undoubtedly, these results are a breakthrough, so regional studies could reinforce the global effort from the local (^{Segura-Castruita et al., 2005}), especially for arid and semi-arid regions where C sinks have been underestimated (^{Montaño et al., 2016}).

Therefore, the objectives of the present study were to estimate the magnitude of SOC stocks in the Medio Aguanaval River sub-basin (ScRMA) and to analyze the sensitivity of four interpolation methods to minimize the digital mapping error for the ScRMA.

Materials and methods

Description of the study unit

The ScRMA was considered as the study unit, located in the Mesa del Centro province and in the sub-provinces Sierra and Llanuras del Norte, and Sierras and Lomeríos de Aldama and Río Grande, in an altitudinal range from 1 400 to 2 600 m a. s. l. The ScRMA is part of hydrological region 36, with an area of 8 348 km² and located in the east of the state of Durango, northwest of the state of Zacatecas and southeast of the state of Coahuila (24.632° N and 103.260° W) (^{Comisión Nacional para el Conocimiento y Uso de la Biodiversidad [CONABIO], 1998}) (Figure 1).

Figure 1 Study Unit: national, regional and sub-basin location of the Medio Aguanaval river.

The ScRMA includes part of the municipalities of Cuencamé, General Simón Bolívar, Santa Clara and San Juan de Guadalupe in Durango; Juan Aldama and Miguel Auza in Zacatecas, and Torreón and Viesca in Coahuila. The climate in this area is arid, with five subtypes: very arid semi-warm (BWhw), arid semi-warm (BSohw), semiarid temperate (BS1kw), arid temperate (BSokw) and semiarid semi-warm (BS1hw) (^{García, 1998}). There is dominance of scrubland (41 %) and rainfed agriculture, which is practiced in 20 % of the territory (^{Instituto Nacional de Estadística y Geografía [INEGI], 2016}). Precipitation and annual temperature in this area range from 125 to 600 mm and from 16 to 22° C, respectively (^{Cuervo-Robayo et al., 2014}). The ScRMA territory includes 12 main soil groups (MSG) and 39 subgroups, where Phaeozem, with loam or medium texture, stands out in more than 80% of the area (^{INEGI, 2014a}). The presence of topoforms such as mountain ranges, rolling hills, plateaus, plains, valleys and relieves is observed (^{Lugo-Hubp & Aceves-Quezada, 1992}).

Results and discussion

SOC values obtained for the ScRMA ranged from 9 to 133 t·ha^-1, with a mean value of 36.31 t·ha^-1, and a standard deviation of 23.83 t·ha^-1, (Table 1). These values were obtained from information of soil profiles with depths of 12 to 30 cm; considered based on previous regional studies for the same depth range, which is where the highest SOC concentrations are found (^{Burke et al., 1989}).

SOC concentrations varied in the ScRMA; 84.5 % of its extension values ≤ 50 t·ha^-1 were obtained, while 14.5 % of the surface area varied from 51 to 100 t·ha^-1, and almost 1 % had concentrations > 100 t·ha^-1. The first range of SOC concentrations (10 to 50 t·ha^-1) was distributed in 49.80 % of the scrubland area located in the central-northern portion of the sub-basin, specifically northeast of the municipality of Santa Clara, west of San Juan de Guadalupe, south of Viesca, southeast of Torreón and Simón Bolívar, and in a small portion north of Gral. Fco. R. Murguía. 19.63 % of the same concentration occurred in annual rainfed agricultural areas found in the southeastern part of the sub-basin, south of the municipality of Cuencamé, almost in the entirety of Miguel Auza, south of Simón Bolívar and in the center of Juan Aldama. The 11.5% was found in areas of secondary scrubland vegetation, in some parts of the municipalities of Viesca, Torreón, San Juan de Guadalupe and Simón Bolívar. Finally, 10 % occurred in secondary grassland vegetation, in some parts of Juan Aldama, south of Simon Bolivar, Viesca, Cuencamé and Santa Clara. The remaining 9.66% corresponds to land use and vegetation with a distribution of less than 1 % each.

The second range of SOC (51 to 100 t·ha^-1) was found in the west of the sub-basin, where areas with secondary grassland vegetation had this concentration in 42.5 % of their surface, especially in the central-eastern part of Cuencamé and central-western part of Santa Clara. The 24.9 % was distributed in areas with annual rainfed agriculture, in the center-west of Santa Clara, and 22.9 % was in scrubland in the north-northwest part of Santa Clara. Finally, the third range (> 100 t·ha^-1) was located west of the ScRMA, in areas of grassland and secondary grassland vegetation.

When comparing interpolators of the ArcGIS 10.1 program, it was found that IDW and Kriging had the best interpolation based on the basic statistics of mean and standard deviation (Table 2).

In the comparison of the powers of the IDW and Kriging interpolators, it was determined that exponential ordinary Kriging (KO) best represented the SOC values of the ScRMA based on the statistics obtained (Table 3).

^{Villatoro et al. (2008)} compared IDW and Kriging interpolators, because they are the most used in spatial variation analysis studies, in an area of 2 467 m² and georeferenced 61 points at a distance of 3.5 m from each other; soil samples were obtained at a depth of 0 to 15 cm at each point. The authors used the GS+ program for Windows for variogram analysis, interpolation and cross-validation. Interpolations were performed with soil pH, Ca, CEC and phosphorus (P) values, and they determined that, although both interpolators had similar performance, Kriging was superior in predicting better the variation of pH, Ca and CEC, while IDW was better with P.

Interpolation was represented in nine classes to better visualize the SOC distribution (Figure 2). It was observed that values higher than 50 t·ha^-1 are distributed from the central zone towards the west, belonging, in a larger area, to the state of Durango, where lithosol, xerosol and chernozem soil types are found. This zone is dominated by desert microphyllous and rosetophyllous scrub, natural grassland and secondary natural grassland vegetation, with a rainfall of 400 to 600 mm.

Figure 2 Soil organic carbon (SOC) in the Medio Aguanaval river sub-basin obtained using the Kriging interpolator.

The lowest SOC concentration is distributed in the south part of Coahuila and the northeast part of Zacatecas. ^{Vela-Correa et al. (2012)} reviewed the reported SOC concentrations to have a general reference and be able to classify them into high and low, according to their values. These authors concluded that there is no reference where a general hierarchy of SOC is established, so they considered the limits of the intervals according to the maximum and minimum values of C concentration obtained in the soil analyses.

^{Segura-Castruita et al. (2005)} estimated the SOC content in the surface horizon (0 to 20 cm) of 4 583 soil samples and generated a raster map by interpolation. They found values ranging from 0.2 to 493 t·ha^-1, which they divided into five classes. The values corresponding to the sub-basin area ranged from 25 to 50 t·ha^-1, which agrees with the results of this study, with a mean of 36 t·ha^-1. Similarly, the results agree with a study by ^{FAO (2017a)}, where they produced a global organic carbon map with one-kilometer resolution using samples obtained at a depth of 0 to 30 cm. In that study, ScRMA presented SOC values of 25 to 40 t·ha^-1, and in this study a mean of 24.4 t·ha^-1 was obtained in the analysis of ScRMA verification sites (Table 4).

It is important to consider that the number of sites sampled for verification was low (nine sites), although these were representative of the different soil types and uses, compared to the 40 sites analyzed from the INEGI soil profiles, where the mean obtained was 36 t·ha^-1. Nevertheless, the results obtained with soil sampling in the ScRMA were no different from those reported by both ^{FAO (2017a)} and ^{Segura-Castruita et al. (2005)}. Regarding the precision of the estimates made, the ECM (mean squared error) statistic was calculated for the SOC data of the analyzed profiles and verification sites (23.83 and 16.41 t·ha^-1, respectively), and the coefficient of variation for the same data (65.64 and 67.27 %, respectively) (Table 5).

The highest concentration of SOC is found in natural grassland areas, annual irrigated and annual rainfed agriculture, and desert microphilous scrubland that belongs to the central part, which corresponds to the state of Durango (1 600 to 2 200 m a. s. l.).

^{Mondal et al. (2017)} estimated the distribution of SOC in varied categories of slope, soil, and land use, and observed that SOC concentration is higher in low areas and for clay soils of lands with agricultural vocation. These authors also reported that SOC stock decreases with greater slope, and that clay has the highest carbon content in soil categories.

SOC information refers mainly to temperate and tropical regions (^{Segura-Castruita et al., 2005}), because arid and semi-arid regions have been poorly studied. ^{Montaño et al. (2016)} and ^{Yescas-Coronado et al. (2018)} mention that spatio-temporal heterogeneity of these regions is influenced by environmental conditions, plant community type, and land use, which together affect carbon stocks and fluxes.

Several authors indicate that climate, via temperature and precipitation, plays a dominant role in SOC accumulation (^{Grigal & Ohmann, 1992}; ^{Batjes, 1999}; ^{Yigini & Panagos, 2016}; ^{Batjes, 2016}; ^{FAO, 2017c}; ^{FAO, 2019}). Furthermore, it has been determined that soils of rainforests, mangroves and mountain mesophyll forests contribute more than 100 Mg·ha^-1 of CO, while grasslands, desert and thorn forest contribute less than 30 Mg·ha^-1 of CO. On the other hand, when relating the main land uses with SOC content, it was established that soils used for intensive livestock have the highest SOC content (> 80.0 Mg·ha^-1), followed by forest soils (> 75.0 Mg·ha^-1), while irrigated agricultural soils have the lowest amount of this compound (40.8 Mg·ha^-1) (^{Segura-Castruita et al., 2005}).

Therefore, low SOC concentrations (10 to 30 t·ha^-1) in ScRMA are distributed mainly in the northeastern part of the zone, where the dominant vegetation is scrubland (desert) and secondary scrubland vegetation. Precipitation ranges from 125 to 400 mm, and the climate is very arid and semi-warm. SOC concentrations can be attributed to the low contribution of organic matter to the soil by vegetation and aridity of the area, promoting SOC loss.

Conclusions

ScRMA dominated by semiarid conditions showed an estimated mean value of 36.31 t·ha^-1 of SOC. In terms of distribution, the municipalities with the highest SOC concentration were Cuencamé and Santa Clara, while the lowest records were found in Torreón. This interspatial variation depends on climatic and soil variables and the type of management of the area, where the highest SOC content is generated in sites with higher precipitation and soil depth.

The main limitation in this research was the lack of information on apparent density, which affected the precision of SOC reserve estimates. Therefore, and based on the development of this study, it was estimated that at a density of 0.6 % sampling, uncertainty decreased from 23.83 to 16.41 t·ha^-1 (ECM) in this heterogeneous ecosystem.
