Nota científica
Earthquake induces mass-spawning event in two coral-reef sea cucumber
species in Belize
Terremoto induce evento de desove masivo en dos especies de pepino
de mar en arrecifes de coral en Belice
Arlenie Rogers1
*
Jean-François Hamel2
Annie Mercier3
1 Environmental Research Institute, University
of Belize, Belmopan Campus, Price Center Road, UB-Preschool Grounds, Belmopan
City, Belize.
2 Society for the Exploration and Valuing of the
Environment (SEVE), St. Philips (Newfoundland), A1M 2B7, Canada.
3 Department of Ocean Sciences, Memorial
University, St. John’s (Newfoundland), A1C 5S7, Canada.
ABSTRACT
Background:
Electromagnetic pulses that precede earthquakes, and the ensuing crust
deformations and vibrations, have been associated with unusual animal
behavior (UAB), most commonly in terrestrial species but also in certain
marine species, chiefly in the Chordata phylum (e.g. fish, cetaceans).
Goals:
This study explored the occurrence of earthquake-related UAB in an entirely
new marine phylum, the Echinodermata.
Methods:
Formal and informal surveys conducted by fishing vessels preand
post-earthquake along the southern coast of Belize (Central America) were
collated.
Results:
The first cases of post-earthquake UAB in echinoderms were documented. They
involved thousands of individuals of the holothuroids Isostichopus
badionotus and Holothuria mexicana spawning on
May 29, 2009 and January 10, 2018. These rare accounts represent the first
direct correlation between an earthquake and spawning activity, which
occurred outside the normal spawning season and at an unusual time of
day.
Conclusions:
While a growing number of reports indicate that many terrestrial and a
smaller number of marine species can change their behavior before and during
an earthquake, post-earthquake effects related to reproduction have
apparently never been reported before in the animal kingdom. While
underlying mechanisms remain unclear, holothuroid echinoderms may be
reacting directly or indirectly to seismic activity, or the pressure change
generated by it.
Keywords: disturbance; echinoderm; Holothuria mexicana; Isostichopus badionotus; reproduction; unusual animal behavior
RESUMEN
Antecedentes:
Los pulsos electromagnéticos que preceden a los terremotos y las
consiguientes deformaciones y vibraciones de la corteza de la tierra han
sido asociados con el comportamiento animal inusual (CAI), más comúnmente en
especies terrestres sino también en ciertas especies marinas, principalmente
en el filo Chordata (por ejemplo, peces, cetáceos).
Objetivos:
El presente estudio exploró la ocurrencia de CAI relacionada con terremotos
en un filo marino completamente nuevo, el Echinodermata.
Métodos:
Se recopilaron encuestas formales e informales realizadas por barcos
pesqueros antes y después del terremoto a lo largo de la costa sur de Belice
(América Central).
Resultados:
Se documentó el primer caso de CAI post-terremoto en equinodermos. El caso
involucró a miles de individuos de los holoturoidea Isostichopus
badionotus y Holothuria mexicana desovando el
28 de mayo de 2009 y el 10 de enero de 2018, respectivamente. Estas
ocurrencias raras representan la primera correlación directa entre un
terremoto y la actividad de desove, que ocurrió fuera de la temporada de
desove normal y en un momento del día inusual.
Conclusiones:
Mientras que un número creciente de informes indica que muchas especies
terrestres y un número menor de especies marinas pueden cambiar su
comportamiento antes y durante un terremoto, los efectos posteriores al
terremoto relacionados con la reproducción, aparentemente nunca se han
reportado antes en el reino animal. Si bien los mecanismos subyacentes
siguen sin estar claros, los equinodermos holoturoideos pueden estar
reaccionando directa o indirectamente a la actividad sísmica, o al cambio de
presión generado por ella.
Palabras clave: comportamiento inusual; equinodermo; Holothuria mexicana; Isostichopus badionotus; perturbación; reproducción
Perturbations associated with earthquakes, such as changes in atmospheric pressure and
gravity, ground deformations, acoustic signals and vibrations due to micro-crack
generation, and the concurrent emission of gases and chemical substances, have been
documented to cause unusual animal behaviors or UABs (Hayakawa, 2013). Moreover, Freund & Stolc
(2013) showed that electronic charge carriers (called positive holes) were
activated during the build-up of stress deep in the Earth before earthquakes. These
positive holes can travel fast and far into the surrounding rocks, generating ultralow
frequency electromagnetic waves, which may ionize air and generate hydrogen peroxides at
the sea surface (Freund & Stolc, 2013). The
latter authors suggested that the momentary disappearance of the toad Bufo
bufo Linnaeus, 1758 in central Italy about 5 days before the L’Aquila
earthquake of April 2009 (Grant et al.
2011) was triggered by chemical cues in the water, such as the release of
hydrogen peroxide products resulting from an influx of hydron (cationic form of atomic
hydrogen). Other variables related to earthquakes may be at play in the ocean, such as
telluric currents produced through electromagnetic induction by the geomagnetic field or
whenever a conducting body (e.g. seawater) moves because of tides or other processes
across the Earth’s permanent magnetic field (Lanzerotti
& Gregori, 1986). These low-frequency currents travel large distances
near the surface of the Earth (Lanzerotti & Gregori,
1986). In addition, amplitude anomalies of the telluric field have been
detected before shallow earthquakes with magnitudes ≥ 4.5. These amplitude anomalies
reached about 100-300 mv km-1 3-16 days before the earthquake (Myachkin et al. 1972). All the
above-mentioned earthquake-related changes (Nagao
et al. 2002) have been identified as sources of UAB
(Freund & Stolc, 2013), including in
aquatic animals (Tributsch, 1982). For instance,
geomagnetic sensitivity was related to stranding of dolphins and whales (Kirschvink, 1990), and of Humboldt squids (Than, 2009).
Here we describe for the first time an UAB in a member of the Echinodermata phylum and a
side effect recorded post-earthquake. Monitoring the seafloor down to 5 m occurred
during daily fishing activities in Belize (Central America) that included sea-cucumber
harvests south of Laughing Bird Cay and in Port Honduras in 2009 and 2018, respectively.
On January 9, 2018 at 21:51, an earthquake of magnitude 7.6-7.8 was recorded 200 km off
the Caribbean coast of Belize. Aftershocks of magnitude 4.2-5.0 followed in the evening
and early the following day. The earthquake had a shallow focus (~10 km) which amplified
its effects, i.e., increased shaking/vibration levels (USGS, 2018). No tsunami was generated. In the morning of January 10, around
07:00, two species of coral-reef sea cucumbers, Isostichopus badionotus
Selenka, 1867 and Holothuria mexicana Ludwig, 1875, underwent a
mass-spawning event involving thousands of individuals (from the shore to ~5 m depth) in
the entire Fore Reef (about 3.2 km2). This spawning was uncharacteristic in
that it was outside the normal reproductive season and occurred at sunrise rather than
at sunset, as is usually the case (Mercier et
al. 2007). While these sea cucumbers normally shelter in sand,
seagrass, or among corals (especially from early morning to late afternoon), most
individuals had emerged and displayed their typical spawning posture while broadcasting
gametes in the water column (Fig. 1) in full
daylight (the inverse of normal behavior). Inside a shoal area measuring 3.2 km long by
about 1 km wide (16°12’05.61” N; 88°40’04.97” W), which was composed of patch reef and
seagrass, nearly 100% of females and males (representing a maximum of 1-3 ind
m-2) spawned simultaneously for a duration of about 2 h (sexes determined
based on the distinct appearance of male and female gametes in the water column). The
water temperature was 30.9 °C, the salinity 33.6, with a recorded rainfall of 34.5 mm
over the previous 24 h. There was no correlation with the full or new moon (as spawning
after the earthquake occurred 2 days after the third moon quarter), or with the low or
high tide or any Sea cucumbers spawning after earthquake broad environmental factor
known to coincide with the spawning period of those species in the study region,
including a phytoplankton bloom (Rogers et
al. 2018).
Despite a growing number of reports indicating that certain terrestrial and marine
species can display unusual behaviors before and during earthquakes (Bhargava, 2009), to our knowledge no impact on the
timing of reproduction has ever been documented in the animal kingdom. The present
observation may also be the first to show the influence of an earthquake on a
non-vertebrate marine benthic taxon. While explaining correlations of this magnitude is
complex, it may be suggested that sea cucumbers are able to detect seismic events
directly or indirectly, through anomalous telluric current changes, changes in
atmospheric pressure, and changes in gravity, acoustic signals, vibrations, or ultralow
frequency electromagnetic waves generated by earthquakes (Hayakawa, 2013). Exposure to physical stress is a common technique used to
artificially induce sea cucumbers to spawn in captivity, especially in aquaculture
facilities (Mercier & Hamel, 2009), and it can
be assumed that earthquakes generate similar stressors. Despite the present spawning
event was only confirmed from one area of the extensive coral reef system of Belize, it
is not impossible that the phenomenon occurred in other locations along the coast. An
anecdotal correlation between mass spawning of the same sea cucumber species and an
earthquake was observed in Belize ~4 hours after the 7.3 magnitude earthquake that
occurred at 03:24 on May 28, 2009 (Héctor Saldívar, pers. comm., September 2011),
supporting this assertion and the potential disruptive impact of earthquakes on sea
cucumber reproduction. If non-mature gametes are released in full daylight under
out-of-phase conditions, development failure and higher predation pressure are likely to
exacerbate propagule mortality rates.
Overall, the reaction to earthquake documented here may be interpreted as a strategy
developed by slow-moving species to survive dangers by releasing dispersive pelagic
propagules. It remains unclear how sea cucumbers might detect seismic events, although
electric or electromagnetic sensitivity are probable candidates.
